Foodstuff Gravity Filling Machine
Gravity filling machines are the most economical and easy to operate filling machines but have the limit to filling free flowing liquids with very thin viscosity that do not change with ambient temperature or with batch variation. It's widely used to fill food and beverage, cleaning and specialty chemical, pharmaceutical, cosmetic and personal care industries for various low viscous filling projects.
Machine Description :
Time gravity filling machine is the most economical type of time filling machine for a limited range of applications.
The time filling machines work by a simple principle. Liquid is pumped into a holding tank above a set of pneumatically operated valves. Each valve is independently timed by the time flow filling machine master computer so that the precise amount of the liquid will flow by gravity into the containers, Independent timing of each filling valve/nozzle corrects for minor variations in flow rates so that each container is filled accurately. An automatic product level sensing float system detects level of the liquid to maintain pressure so that liquid can flow into containers fast and evenly. When liquid level is low, pump is on, liquid is pumped into holding tank, when liquid reaches high level, pump is off.
Main Technical Parameter:
| 1.Capacity | max 4000 bottles per hour |
| 2.Filling volume | 50-1000ml, 1000ml-5000ml |
| 3.Measurement precision | 50-200ml: ±1%; 200ml-1000ml:±0.5%; 1L-5L: ±0.5% |
| 4.Applicable bottle diameter | 40-100mm |
| 5.Applicable bottle height | 60-300mm |
| 6.Air pressure | 0.6Mpa |
| 7.Total power | 1kw, 1.5Kw |
| 8.Voltage | AC220V,50/60Hz |
| 9.Net weight | 900kg |
| 10.Dimension | 2200(L)×710(W)×2200(H)mm |
After-sales Service:
(1) Under stable voltage, the machines' quality that we sold will be guaranteed for 1 year
(2) Long time technology will be supplied.
(3) We can dispatch our engineer to your side for installing and debugging machines. Engineer's round-trip tickets, accommodation, and your side traveling fee will be charged by you.
We can also supply training process for your engineers who come to china, so you can fit and debug machines by yourself.
